Adjustments

• User Adjustment Range: 7-position seat

• Color-coded pivots & points of adjustment: Yes

Frame & Cables

• Available Frame Colors: Iced Silver, Matte Black, Gloss Black, Lace White, Polarized Titanium

• Frame Finish: Proprietary two-coat powder process

• Cable Transmission: Internally lubricated cables and fittings

• Machine Anchoring: Independent machine hold down brackets

• Integrated Leveling System: Yes, top-down leveler

Tech Specs

• Overall “Static” Dimensions (L x W x H): 116 x 106.5 x 135 cm / 45.75” x 42” x 53”

• Overall “In-use” Dimensions (L x W x H): 144.5 x 106.5 x 135 cm / 57” x 42” x 53”

• Product Weight: 239.2 kg / 527.5 lbs.

• Rep Counter Machine Usage Tracking: Service mode tracks total machine reps and hours of use

• Rep Counter Battery Life: Approximately 3 years

• Rep Counter Power Supply: 2 AA batteries

User Amenities

• Front Placards: Muscle call outs, exercise-specific stretching, start and finish exercise illustrations, proper machine adjustments, color-coded machine identification

• Rear Placards: Color-coded machine identification, exercise-specific stretching

• Placard Color Coding: Yellow (upper body)

• Rep Counter: Electronic counter displays reps, exercise time and rest time

• Personal Storage: Two tactile storage mats, personal device cradle and towel hook

• Action Specific Grips™: Exercise-specific grips improving feel, function and form during use, rotating grips for added comfort

• Pivoting Arm Pads: Yes

• Elbow Wear Covers: Yes

• Contoured Seat: Yes

Weight Stack

• Weight Stack: 81 kg / 180 lbs.

• Weight Plate Increments: 4.5 kg / 10 lbs.

• Incremental Weights: 1.1, 2.3, 3.4 kg / 2.5, 5, 7.5 lbs.

• Max Training Weight: 84.4 kg / 187.5 lbs.

• Max User Weight: 136 kg / 300 lbs.

• Consistent 53” Stack Height: Yes

• Weight Stack Guarding: Full front and rear shields
