Adjustments

• User adjustment range: 4 knee pad start positions on each side

• Color coded pivots & points of adjustment: Yes

Frame & Cables

• Available frame colors: Iced Silver, Matte Black, Gloss Black, Lace White, Polarized Titanium

• Frame finish: Proprietary two-coat powder process

• Cable transmission: Internally lubricated cables & fittings

• Machine anchoring: Independent machine hold down brackets

• Integrated leveling system: Yes — top-down leveler

Tech Specs

• Overall “static” dimensions (L x W x H): 117 x 123 x 141 cm / 45.8” x 48.2” x 55.2”

• Overall “in-use” dimensions (L x W x H): 117 x 123 x 141 cm / 45.8” x 48.2” x 55.2”

• Product weight: 229 kg / 505 lbs.

• Rep counter machine usage tracking: Service mode tracks total machine reps and hours of use

• Rep counter battery life: ~3 years

• Rep counter power supply: 2 AA batteries

User Amenities

• Front placards: Muscle call outs, exercise-specific stretching, start & finish exercise illustrations, proper machine adjustments, color-coded machine identification

• Rear placards: Color-coded machine identification, exercise-specific stretching

• Placard color coding: Green (core)

• Rep counter: Electronic display for reps, exercise time, and rest time

• Personal storage: Two tactile storage mats, personal device cradle, and towel hook

• Contoured seat: Yes

• Knee Pad Wear Cover: Yes

Weight Stack

• Total stack weight: 90 kg / 200 lbs.

• Weight plate increments: 4.5 kg / 10 lbs.

• Incremental weight system: 1.1, 2.3, 3.4 kg / 2.5, 5, 7.5 lbs.

• Max training weight: 93.4 kg / 207.5 lbs.

• Consistent 53” stack height: Yes

• Weight stack guarding: Full front and rear shields
