Adjustments

• User adjustment range: 7 position seat, 6 back pad positions (20° total, 4° per position)

• Machine assisted adjustments: Spring assisted seat, gas assisted back pad

• Color coded pivots & points of adjustment: Yes

Frame & Cables

• Available frame colors: Iced Silver, Matte Black, Gloss Black, Lace White, Polarized Titanium

• Frame finish: Proprietary two-coat powder process

• Cable transmission: Internally lubricated cables & fittings

• Machine anchoring: Independent machine hold down brackets

• Integrated leveling system: Yes, top-down leveler

Tech Specs

• Overall static dimensions (L x W x H): 140 x 141 x 135 cm / 55” x 55.4” x 53”

• Overall in-use dimensions (L x W x H): 168.5 x 141 x 135 cm / 66.3” x 55.4” x 53”

• Product weight: 343.9 kg / 758.5 lbs

• Rep counter usage tracking: Service mode tracks total reps and hours of use

• Rep counter battery life: ~3 years

• Rep counter power supply: 2 AA batteries

User Amenities

• Front placards: Muscle call outs, stretching illustrations, start & finish exercise illustrations, proper machine adjustments, color-coded ID

• Rear placards: Color-coded ID, exercise specific stretching

• Placard color coding: Yellow (upper body)

• Rep counter: Electronic, displays reps, exercise time, rest time

• Personal storage: Two tactile storage mats, device cradle, towel hook

• Action Specific Grips: Yes

• Foot platform: Foot rest for comfort

• Contoured seat: Yes

Weight Stack

• Total stack weight: 108 kg / 240 lbs

• Weight plate increments: 4.5 kg / 10 lbs

• Incremental weight system: 1.1, 2.3, 3.4 kg / 2.5, 5, 7.5 lbs

• Max Training Weight: 111.4 kg / 247.5 lbs

• Consistent 53” stack height: Yes

• Weight stack guarding: Full front and rear shields

Adjustments

• User adjustment range: 7 user start options

• Color coded pivots & points of adjustment: Yes

Frame & Cables

• Available frame colors: Iced Silver, Matte Black, Gloss Black, Lace White, Polarized Titanium

• Frame finish: Proprietary two-coat powder process

• Cable transmission: Internally lubricated cables & fittings

• Machine anchoring: Independent machine hold down brackets

• Integrated leveling system: Yes, top-down leveler

Tech Specs

• Overall static dimensions (L x W x H): 105.5 x 132 x 135 cm / 41.5” x 52” x 53”

• Overall in-use dimensions (L x W x H): 105.5 x 150 x 135 cm / 41.5” x 59” x 53”

• Product weight: 276.8 kg / 610.5 lbs

• Rep counter usage tracking: Service mode tracks total reps and hours of use

• Rep counter battery life: ~3 years

• Rep counter power supply: 2 AA batteries

User Amenities

• Front placards: Muscle call outs, stretching illustrations, start & finish exercise illustrations, proper machine adjustments, color-coded ID

• Rear placards: Color-coded ID, exercise specific stretching

• Placard color coding: Yellow (upper body)

• Rep counter: Electronic, displays reps, exercise time, rest time

• Personal storage: Two tactile storage mats, device cradle, towel hook

• Contoured seat: Yes

Weight Stack

• Total stack weight: 90 kg / 200 lbs

• Weight plate increments: 4.5 kg / 10 lbs

• Incremental weight system: 1.1, 2.3, 3.4 kg / 2.5, 5, 7.5 lbs

• Max Training Weight: 93.4 kg / 207.5 lbs

• Consistent 53” stack height: Yes

• Weight stack guarding: Full front and rear shields
