Adjustments

• User Adjustment Range: 7 Knee pad positions, 3 Back pad angle positions

• Color-Coded Pivots & Points of Adjustment: Yes

Frame & Cables

• Available Frame Colors: Iced Silver, Matte Black, Gloss Black, Lace White, Polarized Titanium

• Frame Finish: Proprietary two-coat powder process

• Cable Transmission: Internally lubricated cables & fittings

• Machine Anchoring: Independent machine hold-down brackets

Tech Specs

• Overall “Static” Dimensions (L x W x H): 182 x 173 x 135 cm / 71.6” x 68” x 53”

• Overall “In-Use” Dimensions (L x W x H): 182 x 173 x 135 cm / 71.6” x 68” x 53”

• Product Weight: 272.2 kg / 600 lbs

• Rep Counter Machine Usage Tracking: Service mode tracks total machine reps and hours of use

• Rep Counter Battery Life: Approx. 3 years

• Rep Counter Power Supply: 2 × AA batteries

User Amenities

• Front Placards: Muscle call-outs, exercise-specific stretching, start & finish exercise illustrations, proper machine adjustments, color-coded machine identification

• Rear Placards: Color-coded machine identification, exercise-specific stretching

• Placard Color Coding: Blue (lower body)

• Rep Counter: Electronic display showing reps, exercise time, and rest time

• Personal Storage: Two tactile storage mats, personal device cradle, and towel hook

• Contoured Seat: Yes

Weight Stack

• Total Stack Weight: 90 kg / 200 lbs

• Weight Plate Increments: 4.5 kg / 10 lbs

• Incremental Weight System: 1.1, 2.3, 3.4 kg / 2.5, 5, 7.5 lbs

• Max Training Weight: 93.4 kg / 207.5 lbs

• Consistent 53” Stack Height: Yes

• Weight Stack Guarding: Full front and rear shields
