Adjustments

• User adjustment range: 7-position seat

• Color-coded pivots & points of adjustment: Yes

Frame & Cables

• Available frame colors: Iced Silver, Matte Black, Gloss Black, Lace White, Polarized Titanium

• Frame finish: Proprietary two-coat powder process

• Cable transmission: Internally lubricated cables and fittings

• Machine anchoring: Independent machine hold down brackets

• Integrated leveling system: Yes, top-down leveler

Tech Specs

• Overall “static” dimensions (L x W x H): 115.5 x 106.5 x 135 cm / 45.5” x 42” x 53”

• Overall “in-use” dimensions (L x W x H): 149 x 106.5 x 135 cm / 59” x 42” x 53”

• Product weight: 225.7 kg / 498 lbs.

• Rep counter machine usage tracking: Service mode tracks total machine reps and hours of use

• Rep counter battery life: Approximately 3 years

• Rep counter power supply: 2 AA batteries

User Amenities

• Front placards: Muscle call outs, exercise-specific stretching, start and finish exercise illustrations, proper machine adjustments, color-coded machine identification

• Rear placards: Color-coded machine identification, exercise-specific stretching

• Placard color coding: Yellow (upper body)

• Rep counter: Electronic counter displays reps, exercise time and rest time

• Personal storage: Two tactile storage mats, personal device cradle and towel hook

• Action Specific Grips™: Exercise-specific grips improving feel, function and form during use, rotating grips for added comfort

• Pivoting arm pads: Yes

• Elbow wear covers: Yes

• Contoured seat: Yes

Weight Stack

• Weight stack: 90 kg / 200 lbs.

• Weight plate increments: 4.5 kg / 10 lbs.

• Incremental weights: 1.1, 2.3, 3.4 kg / 2.5, 5, 7.5 lbs.

• Max training weight: 93.4 kg / 207.5 lbs.

• Max user weight: 136 kg / 300 lbs.

• Consistent 53” stack height: Yes

• Weight stack guarding: Full front and rear shields
