Adjustments

• User Adjustment Range: 7-position seat, 6 back pad positions, total range of 20° (4° per position)

• Machine Assisted Adjustments: Spring-assisted seat, gas-assisted back pad

• Color Coded Pivots & Adjustment Points: Yes

Frame & Cables

• Available Frame Colors: Iced Silver, Matte Black, Gloss Black, Lace White, Polarized Titanium

• Frame Finish: Proprietary two-coat powder process

• Cable Transmission: Internally lubricated cables & fittings

• Machine Anchoring: Independent machine hold-down brackets

• Integrated Leveling System: Yes, top-down leveler

Tech Specs

• Static Dimensions (L x W x H): 140 × 141 × 135 cm / 55″ × 55.4″ × 53″

• In-Use Dimensions (L x W x H): 168.5 × 141 × 135 cm / 66.3″ × 55.4″ × 53″

• Product Weight: 343.9 kg / 758.5 lbs

• Rep Counter Usage Tracking: Service mode tracks total reps and hours of use

• Rep Counter Battery Life: Approx. 3 years

• Rep Counter Power Supply: 2 × AA batteries

User Amenities

• Front Placards: Muscle callouts, exercise-specific stretching, start & finish illustrations, proper adjustments, color-coded identification

• Rear Placards: Color-coded machine identification, exercise-specific stretching

• Placard Color Coding: Yellow (upper body)

• Rep Counter: Displays reps, exercise time, and rest time

• Personal Storage: Two tactile storage mats, personal device cradle, towel hook

• Action-Specific Grips: Optimized feel, function, and form during exercises

• Foot Platform: Foot rest for comfort

• Contoured Seat: Yes

Weight Stack

• Total Stack Weight: 108 kg / 240 lbs

• Weight Plate Increments: 4.5 kg / 10 lbs

• Incremental Weight System: 1.1, 2.3, 3.4 kg / 2.5, 5, 7.5 lbs

• Max Training Weight: 111.4 kg / 247.5 lbs

• Consistent 53″ Stack Height: Yes

• Weight Stack Guarding: Full front and rear shields
