Adjustments

• User Adjustment Range: 7-position seat

• Machine Assisted Adjustments: Spring-assisted seat

• Color-Coded Pivots & Points of Adjustment: Yes

Frame & Cables

• Available Frame Colors: Iced Silver, Matte Black, Gloss Black, Lace White, Polarized Titanium

• Frame Finish: Proprietary two-coat powder process

• Cable Transmission: Internally lubricated cables & fittings

• Machine Anchoring: Independent machine hold-down brackets

• Integrated Leveling System: Yes (top-down leveler)

Tech Specs

• Overall Dimensions (Static / In-Use): 139 × 121 × 147 cm / 54.6” × 47.5” × 57.9”

• Product Weight: 290 kg / 639.5 lbs

• Rep Counter Tracking: Service mode tracks total reps & hours of use

• Rep Counter Battery Life: ~3 years (2×AA batteries)

User Amenities

• Front Placards: Muscle callouts, stretching guides, start/finish illustrations, adjustments, color coding

• Rear Placards: Color coding, stretching guides

• Placard Color Coding: Green (core)

• Rep Counter: Displays reps, exercise time & rest time

• Personal Storage: 2 tactile mats, device cradle, towel hook

• Action-Specific Grips: Yes

• Contoured Seat: Yes

• Elbow Wear Covers: Yes

Weight Stack

• Total Stack Weight: 108 kg / 240 lbs

• Weight Plate Increments: 4.5 kg / 10 lbs

• Incremental Weight System: 1.1, 2.3, 3.4 kg / 2.5, 5, 7.5 lbs

• Max Training Weight: 111.4 kg / 247.5 lbs

• Consistent Stack Height: 53”

• Stack Guarding: Full front & rear shields
