Drive System

• Drivetrain: Flexonic belt

• Drivetrain gear ratio: 1:10

Features

• Power measurement (Watt): No

• Console: Optional LCD

• Generator powered: No

• Training intensity guide: No

• Asset management compatible: No

• Workout tracking compatible: No

• Resistance system: Magnetic

• Emergency stop: Push

• Flywheel: Rear, aluminum, evenly-weighted

• Adjustment type: Quick-touch levers

• Posts & sliders: Aluminum, pin-to-lock adjustment

• Handlebar: Ergo-formed, multi-position, soft PVC

• Handlebar adjustments: Vertical & horizontal

• Saddle: Ergonomically sculpted seat

• Saddle adjustments: Vertical & horizontal

• Water bottle holder: Dual, integrated on handlebar

• Telemetric HR: Yes

• WiFi enabled: No

• ANT+/Bluetooth enabled: No

Frame

• Frame color: Matte black

• Frame material: Steel

• Shrouds & guard: Full frame

• Frame design: Off-set

• Q factor: 168 mm / 6.6”

• Crank type: Forged steel 170 mm / 6.7”

• Pedal type: Dual-sided SPD & toe cage

• Frame stabilizer bars: Oversized, hidden bolts & fixings

• Protection plates: Yes

• Leveling feet: 4

• Transport wheels: 2

Tech Specs

• Overall dimensions (L x W x H): 122.4 x 56.4 x 102.8 cm / 48.2” x 22.2” x 40.5”

• Product weight: 55.2 kg / 121.6 lbs.

• Max user weight: 158.75 kg / 350 lbs.
